29 March

Egg into Flask

Seng Kwang Tan 08 Temperature and Ideal Gases, Demonstrations, IP3 05 Density and Pressure

This classic physics demonstration is used to show the effects of pressure difference between the atmosphere and a cooling volume of air. With a set of clean apparatus, you can even have the egg for a snack after that.

Materials

  1. Hard-boiled Egg
  2. Flask or glass bottle with mouth smaller than the egg
  3. Paper measuring about 2 cm by 5 cm
  4. Lighter

Procedure

  1. Peel the hard-boiled egg.
  2. Light the piece of paper and drop it into the flask.
  3. Place the peeled egg on the mouth of the flask such that the egg seals the flask.
  4. Observe the egg being sucked in while the flame dies.

Explanation

When the burning paper enters the flask, it causes the air within the flask to heat up and expand, with some escaping from the flask. When the egg seals the flask, the flame dies as the paper is about to be burned up while oxygen is also running out.

The air then cools down and the pressure within the flask drops. The pressure due to the atmosphere acting downward on the egg is then greater than that acting upward due to the pressure of the cooling air. This pushes the egg into the bottle.

14 March

15. Electromagnetism

Seng Kwang Tan Subject Content

[accordions autoHeight=’true’]

[accordion title=”1. Definitions”]

  • The magnetic flux density at a point is defined as the force acting per unit current per unit length of the conductor when the conductor is placed at right angles to the field.
  • One tesla is the uniform magnetic flux density which, acting normally to a long straight wire carrying a current of 1 ampere, causes a force per unit length of 1 N m–1 on the conductor.

[/accordion]

[accordion title=”2. Magnetic Fields”]

  • The following are the vector symbols used in diagrams to represent the direction of vectors in 3 dimensional space:
    • $$\rightarrow$$ : on the plane of the page
    • $$\otimes$$ : into of the page
    • $$\odot$$ : out of the page
  • The following are some important points to take note when representing a magnetic field by magnetic field lines:
    • Magnetic field lines appear to originate from the north pole and end on the south pole.
    • Magnetic field lines are smooth curves.
    • Magnetic field lines never touch or cross.
    • The strength of the magnetic field is indicated by the distance between the lines – closer lines mean a stronger field.

[/accordion]

[accordion title=”3. Force on a Current-Carrying Conductor in a Magnetic Field”]

  • When a wire of length $$l$$ carrying a current $$I$$ lies in a magnetic field of flux density $$B$$ and the angle between the current $$I$$ and the field lines $$B$$ is $$\theta$$, the magnitude of the force $$F$$ on the conductor is given by $$F = BIl sin \theta$$.
    magnetic force
  • The directions of the vectors can be recalled by using the Fleming’s Left-Hand Rule.
    Fleming's Left-Hand Rule

[/accordion]

[accordion title=”4. Force on a Moving Charge in a Magnetic Field”]

  • A charge $$q$$ travelling at constant speed $$v$$ at an angle $$theta$$ to a magnetic field of flux density $$B$$ experiences a force $$F = Bqv sin\theta$$.

[/accordion]

[accordion title=”5. Magnetic fields of current-carrying conductors”]

  • Long straight wire
    Right-Hand Grip Rule
  • Flat circular coil
  • Solenoid

[/accordion]

[accordion title=”6. Ferromagnetic Materials”]

[/accordion]

[accordion title=”7. Force between Two Parallel Current-Carrying Conductors”]

  •  Like currents attract and unlike currents repel.

[/accordion]

[/accordions]

08 March

Single Slit Diffraction using Fingers

Seng Kwang Tan 12 Superposition, Demonstrations

This demonstration requires no material other than your own fingers. Hold your index and middle fingers close to each other, leaving a small slit between them about 1 mm in width.

Look through the slit into a source of light such as the window or a lamp. You will need to look with one eye up close to the slit. Warning: do not look directly at the sun.

You will be able to see a number of vertical dark lines between the fingers.

diffraction and interference pattern,

Science Explained

So where do these vertical lines come from? They are dark fringes caused by destructive interference of light when it diffracts through your finger tips.

This phenomenon can be explained using Huygens’ principle. Huygens pictures every point on a primary wavefront as a source of secondary wavelets and the sum of these secondary waves determines the form of the wave at any subsequent time. Hence, each of these secondary wavelets can interference with one another.

Constructive interference takes place when the difference in path lengths between two coherent waves is an integer multiple of the wavelength. This is when the resultant wave is the brightest. Destructive interference occurs when that difference in path length is a half-integer of the wavelength (e.g. $\frac{1}{2}\lambda$, $\frac{3}{2}\lambda$, $\frac{5}{2}\lambda$, etc.) and gives a dark fringe.

The alternating bright and dark fringes is a diffraction pattern, which becomes observable by the eye looking through the slit.

28 February

Ionisation of Air to Remove Static Electric Charges

Seng Kwang Tan 13 Electric Fields, Demonstrations, IP4 10 Static Electricity

Materials

  1. Wool
  2. PVC pipe or plastic comb
  3. String
  4. Lighter

Procedure

  1. Hang the string from an elevated position. Leave the bottom end free.
  2. Rub the PVC pipe with wool. This deposits negative charges, or electrons, onto the surface of the PVC pipe.
  3. Place the side of the pipe that is rubbed near the string. You should notice the string being attracted  towards the PVC pipe.
  4. Holding the PVC pipe still while attracting the string, light a flame using the lighter and place it in between the string and pipe. You should observe the string falling back to its original position.

Science Explained

When air is ionised with the help of a flame, it serves as a conducting medium through which static electric charges can escape from a surface.

27 February

Magnetic Shielding

Seng Kwang Tan 16 Electromagnetism, Demonstrations, IP4 14 Magnetism

Materials

  1. Bar magnet
  2. Paper clip (stainless steel)
  3. Plastic clipboard
  4. Steel bookend

Procedure

  1. Before the demonstration, make sure that the paper clip is not already magnetised by touching it with the steel bookend. If it gets attracted to the bookend, get a new paper clip.
  2. For the demonstration, first show that the paper clip can be picked up by a bar magnet in direct contact.
  3. Next, place the bar magnet on the plastic clipboard and try to pick up the paper clip with the clipboard in between them. Show the audience that the paper clip is attracted.
  4. Finally, place the bar magnet on the steel bookend and attempt to pick up the paper clip with the bookend between them. The paper clip will not be picked up.

Science Explained

Iron and steel are examples of ferromagnetic materials that have their magnetic domains aligned with an external magnetic field when placed in that field. This strengthens the magnetic field but also serves to concentrate the field lines within the ferromagnetic material itself, such that very little of the magnetic field penetrates the “shield”.



26 February

Heat Capacity of Water

Seng Kwang Tan 09 First Law of Thermodynamics, Demonstrations, IP4 18 Thermal Properties of Matter

Water has a high specific heat capacity of about 4200 J kg-1 K-1. When a little bit of water is placed in a balloon, it is able to absorb a significant amount of heat from a candle flame and hence prevent the balloon from bursting.
Materials
  1. Two balloons
  2. Two candles
  3. Lighter
Procedure
  1. In this demonstration, one balloons is filled with about 3 tablespoons of water and then inflated.
  2. Another balloon is inflated to the same size as the first to serve as a control.
  3. Both balloons are then placed vertically over two identical candles. Adjust the balloons such that the distance from balloon to candle is the same for both setups. You can use retort stands to clamp the balloons in place if you have them.
  4. Light the candles with the balloons temporarily removed. The flames will have to touch the bottom of the balloon when they are placed back over the candles.
  5. Observe the balloon without water burst first.
  6. The air gushing out from the exploding balloon may put out the other candle.
  7. If you like, you can keep the balloon with water over the flame for a longer duration. The balloon still will not burst until a long time later.
